ASRS Automated Material Handling System

Place of Origin China
Brand Name Kinte
Certification ISO9001/FEM/ISO14001/OHSAS 18001
Model Number Customized
Minimum Order Quantity Negotiable
Price Negotiable
Packaging Details Packed with plastic films and wrap with strips
Delivery Time According to customer's requirement
Payment Terms Negotiable
Supply Ability Strong production capacity

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Efficiency High Energy Energy-saving
Environment Environmentally Friendly Management System WCS, WMS, TMS, OMS And Others
Industry Cold Storage Minimum Temperature -25°C.
High Light

ASRS Automated Material Handling System

,

WMS Automated Material Handling System

,

ASRS MHS Intelligent Logistics System

Leave a Message
Product Description

ASRS Automated Material Handling System



Efficient Energy-saving Cold Chain ASRS MHS Intelligent Logistics System



The ASRS cold storage takes "efficient, energy-saving, intelligent, environmentally friendly, and fully meets the individual needs of logistics enterprises" as the project design concept. It uses fully automated logistics equipment such as shuttles, hoists, WMS systems, warehousing systems, and monitoring systems, and uses RFID and Barcode technology greatly improves work efficiency, and realizes "first in, first out" and selective shipment of goods to ensure the quality of stored goods.



The ASRS cold storage adopts WCS, WMS, TMS, OMS and other information management systems, which can greatly improve the operating efficiency of the cold storage, and the operating efficiency is 2 to 3 times that of the traditional cold storage.



In terms of intelligent identification of goods, handheld laser scanners (PDA), infrared sensors, GPS and other system equipment are used to realize real-time positioning, tracking, monitoring and management of goods in cold storage. In addition, the Internet of Things technology is used to realize real-time sharing and docking of information sent and received by upstream and downstream enterprises.



The ASRS cold storage adopts professional cold chain logistics management technology, which can ensure the accuracy and operability of product information, realize online query of comprehensive information of cold chain items, and provide customers with traceable services throughout the supply chain of entrusted items.



The superiority of the ASRS cold storage in the refrigeration system is reflected:



(1) High degree of automation. This system is fully automatic operation, and the degree of automation is extremely high, and manual operation is not required during normal operation. When there is a need for manual operation, you only need to issue an instruction to the system, and the system will automatically execute the instruction content, eliminating the potential safety hazards caused by manual operation errors.



(2) Establish customer and product information according to different customers, and each customer has an independent file in the WMS system. The system administrator creates the goods storage list in the WMS system according to the product name, batch number, quantity, specifications and other information according to the customer’s delivery note. At this time, the relevant information of this order is automatically transferred to the PDA handheld computer, and the tally clerk delivers the goods according to the customer. Single check the new receipt information in the PDA and scan the pallet number according to the actual goods. The forklift will put the scanned pallet on the conveyor and automatically put it into the warehouse. After the warehouse, the stacker will send the pallet to the storage location according to the system instructions. After the warehousing is completed, the cargo location information, pallet number information, and product information are bound correspondingly, as the inventory information, the system issues the operation receipt.



(3) Choose storage according to product characteristics, and store different products in partitions. Inbound products can be stored in isolation. According to different product characteristics and customer needs, the WMS system divides the product storage status into qualified products, pending inspections, unqualified products, etc. Inventory products can be inquired online through related information such as product specifications, batches, suppliers, etc., so as to achieve full monitoring of the stored products.



(4) The system administrator establishes the goods delivery list according to the customer's order and sets it in the system according to the customer's individual needs. The system can carry out "first-in, first-out" or selective delivery of batches of products.



(5) After the document picking is completed, the system administrator clicks on the outbound product. At this time, the stacker will automatically find the outbound product location according to the bill information and leave the warehouse. The tally will arrange the delivery operation according to the display screen of the shipment port. After the operation is completed, the system issues the operation receipt.



Scope of application: warehouses in cold chain logistics, fresh food e-commerce, third-party logistics, medicine and other industries can store and distribute goods safely and stably, with a minimum temperature of -25°C.



ASRS Automated Material Handling System 0
